Maintenance Specs
Spark Plug Gap :
0.6mm-0.7mm
Valve Clearance :
0.10mm ( inlet )
0.10mm ( ext )
Engine oil Recommended Specifications :
Engine oil Recommended for winter :
Engine oil Recommended for summer :
Recommended engine oil viscosity under 30 degrees celsius :
Recommended engine oil viscosity under 40 degrees celsius :
Recommended engine oil viscosity over 40 degrees celsius :
Engine Oil quantity :
Engine Oil quantity after engine overhaul :
20W - 40 , API SG , JASO MA
10W - 30 , API SG , JASO MA
SAE 10w-40 fully synthetic
SAE 10w-30
SAE 10w-40
SAE 20w-50
600ml
800ml
Engine Oil Change interval :
Air Filter maintenance or change interval :
2000km
Clean every 2000 km or earlier
Replace every 4000 km or earlier
Chain Slack :
20mm - 30mm
Front axle torque :
4.0 - 5.0 kgf.m( 29.00 - 36 Foot Pounds )
Rear axle torque :
4.0 - 5.0 kgf.m( 29.00 - 36 Foot Pounds )
1.8 - 2.5 kgf.m(13.00 -18.00 Foot pounds )
Stopper arm nut torque :
2mm - 6mm
Throttle FreePlay :
Front Brake Freeplay :
Rear Brake Freeplay :
10mm - 20mm
20mm - 30mm
Fuse on battery :
7A
Recommended Tire Pressure :
Front 25 Psi
Rear 29 psi
and 33 psi with pillion
Gear Shaft Oil Seal :
11.6 - 24.00 - 10.00
Kick Shaft Oil Seal :
13.70 - 24.00 - 5.00
magnet Side Oil Seal :
18.90 - 30.00 - 5.00
Sproket Oil Seal :
27.00 - 39.00 - 10.50
Clutch side Seal :
12.00 - 21.00 - 4.00
Drive shaft Oil Seal :
17.00 - 29.00 - 5.00
Front Forks Oil Seal :
25.00 - 35.00 - 9.00/10.00
